Basic Info.
Model NO.
BVFA
Connection Form
Flange
Driving Mode
Manual
Nominal Pressure
150lb
Channel
Straight Through Type
Structure
Ball
Type
Floating Ball Valve
Function
Floating Ball Valve
Temperature
Normal Temperature
Standard
ASME ISO GB DIN
Application
Industrial Usage
Working Pressure
150lb/300lb/600lb
Port Size
1/2" to 8"
Warranty
1 Year
Customized Support
OEM, ODM, Obm, Software Reengineering
Valve Test
100% Quantity Tested Before Delivery
Transport Package
Wooden Case by Sea
Specification
1/2′′ to 8"
Trademark
ZQV
Origin
Zhejiang, China
HS Code
8481804090
Production Capacity
20000PCS/Month
Packaging & Delivery
Package Size
30.00cm * 16.00cm * 20.00cm
Package Gross Weight
20.000kg
Product Description
Port: Full Port/Reduced Port
Size: 1/2" to 8"
Pressure: 150LB,300LB,600LB
Body: Carton Steel /Stainless Steel
Size: 1/2" to 8"
Pressure: 150LB,300LB,600LB
Body: Carton Steel /Stainless Steel
SEAT: RPTEF/TFM1600/NYLON/DEVLON
Max Temp: 450ºF 232ºC
Ends: ASME B16.5-RF
Max Temp: 450ºF 232ºC
Ends: ASME B16.5-RF
ASME B16.5-TRJ
AS 2129-Table E/Table F
Din2633- RF
Features:
2-Piece Investment Casting Body
2-Piece Investment Casting Body
ISO 5211 Mounting Pad
Adjustable Packing Gland
Blow-out-Proof Stem
Lockable Lever & Spring Return Handle
Adjustable Packing Gland
Blow-out-Proof Stem
Lockable Lever & Spring Return Handle
Anti-Static Device
Pneumatic actuator
Test Standard: API 598/API 607/NACE MR-0175
Design Standard:ASME B16.34& ASME B16.10
| Item | PART | MATERIAL |
| 1 | BODY | ASTM A216-WCB |
| 2 | SEAT | PTFE |
| 3 | BALL | ASTM A182 F304 |
| 4 | GASKET | PTFE or SS+Graphite |
| 5 | BOLTS | ASTM A2193 B7 |
| 6 | NUTS | ASTM A194 2H |
| 7 | BONNET | ASTM A216-WCB |
| 8 | SPRINGS | Stainless Steel |
| 9 | ANTI STATIC | Stainless Steel |
| 10 | THRUST WASHER | PTFE |
| 11 | STEM | ASTM A182 F304 |
| 12 | STEM PACKING | PTFE or SS+Graphite |
| 13 | GLAND RING | SS304 |
| 14 | SPRING | SS304 |
| 15 | LOCKING | Stainless Steel |
| 16 | HANDLE | Stainless Steel |
| 17 | NUTS | ASTM A194 8 |
Q1. Can I have a sample order for valve?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock.Otherwise it is 15-20 days if the goods are not in stock, it is according
to quantity.
Q3. Do you have any MOQ limit for valve order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by sea. It usually takes 30 days to arrive. Airline shipping also optional.
