Basic Info.
Model NO.
Q941F
Connection Form
Flange
Driving Mode
Manual
Nominal Pressure
Pn16
Channel
Straight Through Type
Structure
Floating Ball Valve
Type
Floating Ball Valve
Function
Shut-off
Temperature
-20~232
Application
Water, Oil, Air
Size Range
Dn15~Dn200
Body Material
CF8/CF8m
Ball Material
Ss304/ Ss316
Operation
Electric Actuator
Transport Package
Carton Box+Plywood Case
Specification
CE
Trademark
WENBAO
Origin
China
HS Code
8481804090
Production Capacity
10000PCS/Month
Packaging & Delivery
Package Size
100.00cm * 100.00cm * 100.00cm
Package Gross Weight
600.000kg
Product Description
WB-64 2PC Electric Actuated Stainless Steel Flanged Ball Valve
Features:
FACE-TO-FACE: GB/T12221-1989
FLANGE END DIMENSIONS: GB/T9113.1-2000
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
INVESTMENT CASTING BODY
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308
Main Parts and Materials
1 | Body | CF8/CF8M | 7 | Cap | CF8/CF8M |
| 2 | Seat | PTFE | 8 | Stem | SS304/SS316 |
| 3 | Ball | SS304/SS316 | 9 | Thrust Pads | PTFE |
| 4 | Bolt | SS/SS316 | 10 | O-Rings | Viton |
| 5 | Gasket | PTFE | 11 | Packing | PTFE |
| 6 | Nut | SS/SS316 | 12 | Gland | SS/SS316 |
Company Overview
Wenbao Valve Co.,Ltd was established in 1985. The main products range are as following: Fully Welded Ball Valve,1PC/2PC/3PC Flanged Ball Valve, Threaded Ball Valve, Mini Ball Valve, High Pressure Ball Valve, Pneumatic Ball Valve, Electric Ball Valve, Sanitary ball valve, Ball valve with mounting pad and other valves like gate, globe, check valves and Strainer, etc. Main material include: Stainless steel, Cast Steel, Forged Steel and Brass, etc. The products manufactured as per API, ANSI, JIS, ISO, BS, JB and GB, and have CAD valve design and quality testing center. The products are widely used in chemical industry, oil, metallurgy, light industry, electric power, food, pharmacy, civil industry, fiber industry, liquefied natural gas, liquefied petroleum gas, steel mills, heating pipes, etc. Our company passed the ISO 9001:2008, Standards Organization of Nigeria(SON), International Quality Award Certificate, Manufacture License of Special Equipment, KC of South Korea,CE of Europe, etc.
