Basic Info.
Model NO.
SD341X-16Q
Connection Form
Flange
Structure
Centre Sealing
Seal Form
Force Sealed
Valve Stem
Normal
Work Pressure
Low Pressure (Pn<1.6mpa)
Working Temperature
Normal Temperature (-40°C<T<120°C)
Material of Seal Surface
Soft Sealed
Valve Body
Casting
Standard
GB/T12238 API609 BS5155 En593
Application
Water Industrial Usage
Sealing Material
EPDM
Valve Sheet Material
Ductile Iron
Valve Body Material
Ductile Iron
Brake
Worm Gear
Transport Package
Wooden Case Packing
Specification
DN32-DN1600
Trademark
FVT
Origin
Tianjin, China
HS Code
8481809000
Production Capacity
100000pieces/Years
Packaging & Delivery
Package Size
605.80cm * 243.80cm * 259.10cm
Package Gross Weight
10.000kg
Product Description
Product feature
1,Meet a variety of flange connection standard, is suitable for the PN10/PN16/150LB/5K/10K
2,Flange with Expansion, Adjustable Lengths
3,It is designed without axle pin,reduce valve leakage points
4,The material of each part can be customized according to the requirements
1,Meet a variety of flange connection standard, is suitable for the PN10/PN16/150LB/5K/10K
2,Flange with Expansion, Adjustable Lengths
3,It is designed without axle pin,reduce valve leakage points
4,The material of each part can be customized according to the requirements
| NO. | 1 | 2 | 3 | 4 | 5 | 6 | 7 |
| Name | Stem | Handle lever | Shaft sleeve | Sealing ring | Body | Seat | Disc |
| Material | Galvanized 45 gauge steel | Stamped iron handle | Polymer composite | EPDM | Ductile iron | EPDM | Ductile iron |
| Product parameter | |
| Face to Face Design | ISO 5752-20/EN558-1/GB-T12221 |
| Flange Connection | ANSI Class125/150 JIS 5/10/16K AS2129 TableD/E BS4504 EN1092 PN6/10/16 |
| Working Pressure | 10/16bar |
| Testing Pressure | Shell Test:24bar / 2.4Mpa Seal Test:17.6bar/1.76Mpa |
| Working Temperature | -10°-120° |
| Nominal diameter | DN32-DN300 |
Optional material
(According to your requirements to give you different material choices)
| NO. | Body | Disc | Seat | Stem | Type of Operation |
| 1 | Ductile iron | Ductile iron | EPDM | Galvanized 45 gauge steel | Stamped iron handle |
| 2 | Stainless steel 304/316/316L | Stainless steel 304/316/316L | PTFE | Stainless steel 420/431 /304/316/316L | Cast iron handle |
| 3 | Aluminium alloy | Aluminum bronze | NBR | Die cast aluminum handle | |
| 4 | Cast steel | Stainless steel sulfide polytetrafluoroethylene | Heat-resistant EPDM | Motorized | |
| 5 | Cast iron | Ductile iron covered with nylon | Wear-resistant EPDM | Stainless steel stamped handle | |
| 6 | Aluminum bronze | Ductile iron covered with vulcanized rubber | Fluorine rubber | Stainless steel cast handle | |
| 7 | Stainless steel coated with PTFE | Silicone rubber | pneumatic | ||
| 8 | Ductile iron spray epoxy resin | Hypalon rubber | Duplex stainless steel 2205/2507/1.4469/1.4529 | Worm gear box | |
| 9 | Stainless steel spraying Halar | HNBR | Worm gear box with signal | ||
| 10 | Stainless steel sprayed nano-ceramics | Neoprene rubber | Hydraulic maneuver | ||
| 11 | Stainless steel coated with tungsten carbide | Rubber without copper or zinc | Copper alloy | ||
| 12 | Duplex stainless steel 2205/2507/1.4469/1.4529 | Insulating rubber |
Optional parameter
| NO. | Temperature | Stressstress | Specification | Flange connection standard | Structural form |
| 1 | -20~80° | PN6 | GB/T 12238 | DIN2543-2545 | Center line |
| 2 | -20-120° | PN10-16 | API 609 | ANSI B16.5 | Double eccentric |
| 3 | 0-150° | PN25 | BS 5155 | JIS B2220 | Triple eccentric |
| 4 | -20-200° | JIS5K/10K | EN 593 | BS4504 | |
| 5 | 125LB/150LB | EN1092 |
Product Details
