Basic Info.
Model NO.
B55F
Connection Form
Flange
Structure
Centre Sealing
Seal Form
Force Sealed
Valve Stem
Normal
Work Pressure
Mid-Pressure (2.5mpa< Pn <6.4mpa)
Working Temperature
-20 to +200 Degree Centigrade
Material of Seal Surface
PTFE,Rptfe
Valve Body
Casting
Standard
API598
Application
Industrial Usage, Water Industrial Usage
Body Material
CF8m, CF8, Wcb, 904L
Seat Material
PTFE,P287
Connection
Flanged Ends According to En1092-1
Pressure Rating
Pn40 for DN15-DN50, Pn16 for DN65- DN100
Face to Face
DIN3202 F4
Transport Package
Plywood Case
Specification
DN15-DN200
Trademark
ABC
Origin
China
HS Code
8481804090
Production Capacity
10000 Sets Per Year
Packaging & Delivery
Package Size
65.00cm * 50.00cm * 40.00cm
Package Gross Weight
35.000kg
Product Description
Series B55F PTFE lined ball valve with its body and ball full encapsulated by PFA, FEP or PTFE is for top corrosion medium with high reliability and safety.
FEATURES
• Exchangeable PTFE seat rings.
• Dovetail grooves machined into the body ensure locking of the lining to the body and reduce the effect of liner loading at the flanges.
• Metal to metal body joints ensure lining not squeezed out by pressure or thermal cycling.
• One piece Ball/Stem design for both regulating and shut off (B55F1), two piece Ball/Stem design for pressure up to 25bar (B55F2).
• Self adjusting packing of V-rings by a permanent spring loading provides stem seal integrity while maintaining low
turning torque.
• Full port flow path is designed for minimum pressure drop.
| B55F1 PARTS LIST AND MATERIAL SPECIFICATION | ||
| No. | Part name | Material |
| 1 | Body | ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M |
| 2 | Lining | FEP,PFA,PTFE |
| 3 | Ball/stem | WCB/SS304/SS316 full encapsulated by FEP/PFA/PTFE |
| 4 | Seat | PTFE |
| 5 | Packing gland | ASTM A351 CF8 |
| 6 | Bracket | ASTM A351 CF8, ASTM A351 CF8M |
| 7 | Chevron ring | PTFE |
| 8 | Packing sleeve | PTFE |
| 9 | Packing bushing | SS304, SS316 |
| 10 | Gland ring | SS304, SS316 |
| 11 | Belleville washer | SS301 |
| 12 | Body Bolt | SS304 |
| 13 | Body Nut | SS304 |
| 14 | Bracket bolt | SS304 |
| 15 | Bracket nut | SS304 |
| 16 | Gland bolt | SS304 |
| 17 | Gland nut | SS304 |
| B55F2 PARTS LIST AND MATERIAL SPECIFICATION | ||
| No. | Part name | Material |
| 1 | Body | ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M |
| 2 | Lining | FEP,PFA,PTFE |
| 3 | Ball | WCB/SS304/SS316 full encapsulated by FEP/PFA/PTFE |
| 4 | Seat | PTFE |
| 5 | Stem | SS304, SS316 |
| 6 | Packing gland | ASTM A351 CF8 |
| 7 | Chevron ring | PTFE |
| 8 | Stem lining | FEP,PFA,PTFE |
| 9 | Gland | ASTM 351 CF8, ASTM A351 CF8M |
| 10 | Gland bolt | SS304 |
| 11 | Gland nut | SS304 |
| 12 | Body Bolt | SS304 |
| 13 | Body Nut | SS304 |
