Product Description
| Body type | AOC-3843 | AOC3844 |
| Body size | 1/2''(40A)-6''(600A) | 1/2''(40A)-24''(600A) |
| Body rating | ANSI 150-2500 | ANSI150-2500 |
| Fluid temperature | -45~+200ºC | -45~+538ºC |
| Connections | RF/BW | |
| Body materials | A216WC,A217WC6/9,A351CF8,A351CF8M etc | |
| Ball Materials | A182 F304/F316/316L | |
| Ball Treatment | Polishing/Hard Chromium Plating | Hard Chromium/Surfacing STL/Spary Ni60/Sparyed tungsten carbide |
| Sealing Ring | PTFE/RTFE | Surfacing STL/Spary Ni55/Sparyed tungsten carbide |
| Valve seat leakage | API 598 0 leakage | ANSI B16.014V API598 0 leakage |
Crafted with unrivaled precision, the ball and seat of these exceptional valves are reinforced with state-of-the-art hard coatings of chrome carbide or tungsten carbide. This superior fortification offers remarkable resistance to both erosion and abrasion, significantly enhancing the longevity and reliability of the valves. Experience the advantage of unparalleled durability and superior performance.
Our SNT High-Performance Soft Seated Ball Valves are enhanced with a cutting-edge HVOF coating system. Each valve is subjected to meticulous mate-lapping using proprietary techniques to ensure a flawless 100% sealing capability. The innovative live loading feature guarantees zero emissions, while the ball remains in constant, gentle contact with the seat, effectively wiping away contaminants. This pioneering self-cleaning mechanism prevents interference and potential damage from particles, making these valves the ideal choice for slurry and abrasive service applications. Trust in innovation that sets new standards of excellence.
Ingeniously designed anti-blow out feature ensures the stem remains securely in place, preventing any potential damage caused by blowouts.
The innovative seat ring structure, featuring a wave spring and dual-scraper mechanism, effectively cleans the ball surface while maintaining a robust seal.
Our advanced dual-sealing system assures the highest leakage class, cleverly designed to ensure the flow never comes into contact with the spring.
The efficient design of our draining and sweeping mechanism effectively prevents jamming by thoroughly cleaning the valve.
Engineered to meet API 607 standards, our valves offer outstanding fireproof and anti-static capabilities, ensuring safety and compliance.
Their Outstanding Features Include:
Streamlined design that ensures effortless disassembly with minimal effort.
Incorporating a non-tight fit design, our ball valves are engineered for easy maintenance. This feature enables quick servicing and reduces downtime during routine maintenance, enhancing operational efficiency.
State-of-the-art sealing technology ensures maximum security and reliability.
The multi-layer sealing system, employing a combination of O-ring and either graphite or PTFE, provides dual protection for the stem and body, delivering unparalleled sealing performance.
Our pioneering design satisfies the stringent TA-Luft/Shell SPE 77/312 standards, highlighting our commitment to excellence.
Extended Service Life for Superior Cost-Efficiency
Through advanced processes like spray welding, spraying, and fusion welding, our metal seated ball valves achieve a hardness range of HRC58-73, and a binding force of 80-40MPa. With a remarkable operational life exceeding 100,000 on-off cycles and a leakage class of ANSI VI, these valves exemplify longevity and cost efficiency.
Modular Design for Enhanced Convenience
With a modular inner sealing design, our valves allow seamless interchangeability between soft and metal seats, providing flexibility and dependable performance.
Varied Connection Types for User Convenience
Our valves come in diverse connection types such as flanged (RF, FF, FM, G, RJ), screw-thread, and BW. Each type adheres to international standards, ensuring seamless integration and user-friendly operation.
Extensive Application Experience Guarantees Reliability
SNT Valves have established a formidable reputation through extensive application in petroleum, chemical industries, light industries, pharmaceuticals, paper-making, metallurgy, and power stations. We consistently deliver solutions tailored to specific service conditions, ensuring market-leading reliability and customer satisfaction.
SNT Machinery (Qingdao) Co., Ltd stands as a beacon of innovation and excellence in the realm of control valves. Nestled in the picturesque coastal city of Qingdao, within the Shandong province, our expansive 42,000m² facility is a testament to our commitment to quality. Equipped with cutting-edge workshops and advanced production machinery, we seamlessly integrate production, design, sales, and service. As a high-tech enterprise with exclusive intellectual property, we leverage global management and production expertise to deliver unparalleled quality. Our dynamic workforce of over 150 professionals includes a robust R&D team, with 15% dedicated to pioneering research and 30% holding advanced degrees. Guided by a commitment to excellence, we craft top-tier valves tailored for the petrochemical, oil, and coal chemical industries. By 2017, our sales revenue had impressively climbed to nearly 100 billion, underscoring our market leadership.
SNT proudly possesses the coveted TS special equipment manufacturing certificate and ISO 9001 accreditation, underscoring our commitment to superior quality and safety standards. Our industry credentials are bolstered by net qualification certificates from giants such as SINOPEC, CNOOC, PETROCHINA, and SINOCHEM. Our extensive portfolio includes numerous national patents, reflecting our innovative prowess. We specialize in designing and manufacturing a comprehensive suite of valves that conform to ANSI, API, DIN, BS, and JIS standards. By merging the finest features of globally renowned valves with our proprietary R&D insights, we offer a diversified range of products, including GLOBE, High Pressure Boiler Blow-down Valves, High-Performance Butterfly Valves, Angle-Regulating Valves, and Eccentric Rotary Valves.
Our remarkable product catalog is further enriched by T Three-eccentric Center Butterfly Valves, V Ball Valves, High Wear-resistant Ball Valves, High Pressure Steam Valves, Micro-flow Control Valves, and Self-operated Control Valves. We accommodate various driving mechanisms, including manual, power-driven, pneumatic, and hydraulic operations. Our main component materials, such as A216WCB, A217 WC6/WC9, and A351 CF8/CF8M/CF3/CF3M, are selected for optimal performance. Our valves span sizes from 1/2" to 120" and are engineered to withstand pressures from ANSI 150# to 2500#, operating efficiently in temperatures ranging from -196ºC to 1100ºC.
By harnessing advanced production technologies and a rigorous quality assurance framework, SNT valves have become indispensable across diverse industries such as petrochemical, oil, steel & iron, paper manufacturing, and power stations. Our esteemed clientele, including SINOPEC QILU branch, SINOPEC Qingdao branch, CNOOC Huizhou Refinery, PETROCHINA Guangxi branch, PETROCHINA Ningxia branch, and SINOPEC Changling branch, attest to our reliable performance and industry trust.
Driven by the mission to amplify customer profitability, we are devoted to forging an unparalleled standard of quality and building a reputable brand. Our comprehensive quality assurance and after-sales service systems ensure that SNT valves foster long-lasting and prosperous partnerships with all our clients.
