Basic Info.
Model NO.
Q41 Forged Floating Metal Seated Ball Valve
Connection Form
Sw, NPT, Bsp, Bw, RF, Rtj
Driving Mode
Handle, Pneumatic Actuator, Electric Actuator
Nominal Pressure
150lb~2500lb;Pn16~Pn42
Channel
Full Bore, Reduce Bore
Structure
Floating Ball Valve
Type
Floating Ball Valve
Function
Blow-Down Valve, Atmospheric Valve
Temperature
150lb~2500lb;Pn16~Pn42
Standard
API 608, API 602
Application
Industrial Usage, Water Industrial Usage
Ball Material
F304, F316, F304L, F316L, F51, F60
Seat Material
PTFE, Rptfe, Devlon
Ball
Solid Ball
Valve Bonnet
Bolted Bonnet, Welded Bonnet
Pre-Temp. Rating
API 602
Special
Nace Mr-0175
Valve Test Standard
API 598
Company Certificate
API6d/CE/ISO9001/ISO14001
Valve Test
100% Quantity Tested Before Delivery
Test Certificate
En1024 3.1 Certificate, Provide Rt, Mt, PT, Ut
Our Parterner
Pdvsa, Bp, Sinopec Group, Hitachi etc
Supplier
Factory Direct
Valve Guarantee
18 Months
Transport Package
Plywood Wooden Case
Specification
100X100X10
Trademark
SHF
Origin
Jingshu, China
HS Code
8481804090
Production Capacity
50000000
Packaging & Delivery
Package Size
30.00cm * 20.00cm * 19.00cm
Package Gross Weight
12.000kg
Product Description
Construction is as follows
| Name | Forge Ball valve |
| Size | 1/2"~2-1/2"; DN15~DN65 |
| Normal pressure | 150LB~2500LB;PN16~PN42 |
| Design standard | API 608,BS5351,ISO17292,API 602, BS5352,AMSE 16.34 |
| Marked | MSS SP-25 |
| Thread Connection Dimensions | ANSI B1.20.1; BS21; JIS BO20;JB/T 73.6 |
| SW dimension | ANSI B16.11;JIS B2306;JB/T 1751 |
| BW dimension | ASME B16.25; DIN 3239,EN12627; JB/T12224 |
| End flange | ANSI B 16.5,EN1092,DIN2543~DIN2547 |
| Face to Face | ANSI B 16.10, DIN3202,EN558-1,EN12982,ISO 5752 |
| Test standard | API598,DIN3230, EN12266,ISO 5208 |
| Suitable temperature | -29~150°C |
| Medium | Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc. |
| Acidic environment | NACE MR0175 |
Structure
| - Full Port or Reduce Port |
| - Split Body |
| - Bolted Bonnet with spiral-would gasket |
| - Fire Safe Design |
| - Anti-static Design & Blow-out proof stem |
| - Double seat structure |
| - Butt Weld Ends to DIN 3239,EN12627; ASME B16.25 |
| - Flanged Ends to EN1092,DIN2543~DIN2547; ASME B16.5 |
| - Full Port or Reduce Port |
| - Split Body |
Main Part & Materials
| Part Names | Part Materials | ||||||||||||||
| Body | A105 | LF2 | F11/F22 | F304 | F316 | F304L | F316L | F51/F53 | |||||||
| Bonnet | A105 | LF2 | F11/F22 | F304 | F316 | F304L | F316L | F51/F53 | |||||||
| Ball | F304 | F304 | F304 | F304 | F316 | F304L | F316L | F51/F53 | |||||||
| Stem | F6a | F304 | F6a | F304 | F316 | F304L | F316L | F51/F53 | |||||||
| Seat/Seat Ring | RPTFE/PTFE/TEFLON/PEEK/NYLON/DELRIN | ||||||||||||||
| Packing | Graphite/PTFE | ||||||||||||||
| Bonnet Gasket | PTFE,SS304+Graphite/SS316+Graphite | ||||||||||||||
| Bolts/Nuts | B7/2H | L7/4 | B16/4 | B8/8 | B8M/8M | B8/8 | B8M/8M | B8M/8M | |||||||
| Suitable Medium | W.O.G etc. | HNO3, CH3OOH etc. | Urea etc. | ||||||||||||
| Suitable Temperature | -29~150 °C | -46~150°C | -29~150 °C | --29~150 °C | -29~150 °C | --29~150 °C | -29~150 °C | -29~150 °C | |||||||
Detail size
Product display
Company Introduction
FAQ
Q:Why choose us ?
A: we are a manufacturer, we have manufactured valve for over 20 years .
B. We have our own casting foundary in a large scale
Q. what is your payment term?
A: T/T , L/C or other acceptable payment.
Q:Can we print our logo on your products?
A: yes, we offer OEM/ODM service, we support the customized logo, size, package,etc.
Q: what is your main market?
A: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Q: Can I get samples from your factory?
A: Yes, Samples can be provided.
Q: If products have some quality problem, how would you deal with?
A: We will responsible for all the quality problems.
Q:How about your capacity?
A:We have 300staffs,own 50 CNC machines,and five persons in charge of quality inspection and 5 engineers. Our 6 casting block workshops
can both ensure on time delivery and quality that last.
