Product Description
| Body type | AOC-3841 | AOC3842 |
| Body size | 1/2''(15A)-6''(150A) | 1/2''(15A)-6''(150A) |
| Body rating | ANSI 150-600 | ANSI150-600 |
| Fluid temperature | -45~+200ºC | -45~+538ºC |
| Nominal diameter | DN15-DN150 | DN15-DN150 |
| Connections | RF/BW | |
| Body materials | A216WC,A217WC6/9,A351CF8,A351CF8M etc | |
| Ball Materials | A182 F304/F316/316L | |
| Ball Treatment | Polishing/Hard Chromium Plating | Hard Chromium/Surfacing STL/Spary Ni60/Sparyed tungsten carbide |
| Sealing Ring | PTFE/RTFE | Surfacing STL/Spary Ni55/Sparyed tungsten carbide |
| Valve seat leakage | API 598 0 leakage | ANSI B16.014V API598 0 leakage |
The ball and seat within our valves are fortified with a robust hard coating of chrome carbide or tungsten carbide, renowned for their superior resistance to erosion and abrasion. This advanced treatment ensures durability and longevity under the most demanding conditions.
At SNT, we employ the cutting-edge HVOF coating system. With our proprietary mate-lapped technique, we guarantee 100% sealing integrity. The inclusion of live loading further assures zero emissions, maintaining environmental standards. Designed for optimal performance, the ball remains in constant contact with the seat, effortlessly wiping away contaminants. This self-cleaning mechanism protects against interference and potential damage from debris, making this valve the ideal choice for both slurry services and abrasive operations.
Distinctive Features and Characteristics:
Ingenious, Simple Structure Ensures Effortless Disassembly
With regular maintenance intervals, our ball valves are designed for user-friendly servicing. The non-tight fit design reduces maintenance time, offering unparalleled convenience.
Innovative Sealing for Enhanced Security
The multi-layer combined sealing system of the stem and body provides robust double sealing with a blend of O-ring and graphite or PTFE, ensuring reliability.
This expertly crafted design complies with TA-Luft and Shell SPE 77/312 standards.
Extended Service Life for Unmatched Cost-Effectiveness
For metal-sealed ball valves, advanced techniques like spray welding, spraying, and fusion welding are employed for the ball and seat ring. This ensures a hardness level of HRC58-73 and a binding force range of 80-40MPa, enabling over 100,000 on-off cycles with leakage class conforming to ANSI VI.
Modular Design Offers Supreme Flexibility
The innovative modular design of the inner sealing allows for interchangeable soft and metal seats, ensuring adaptability and seamless performance.
Diverse Connection Types for Optimal Ease of Use
Our valves offer various connection types, including flanged (RF, FF, FM, G, RJ), screw-thread, and BW types, all adhering to international standards, providing utmost convenience and ease of use.
Extensive Application Experience Guarantees Unshakable Reliability
SNT Valves are renowned for their widespread use in industries such as petroleum, chemical, light industry, pharmaceuticals, paper-making, metallurgy, and power stations. Our esteemed reputation in the market is built on delivering tailored solutions based on specific service conditions.
Our innovative packing combination is engineered to excel! It not only meets the stringent emission requirements of 100 ppm but also reduces stem friction by an impressive 20%.
2. Equipped with a wave spring and dual-scraper seat ring, our design ensures the ball surface is meticulously cleaned while maintaining impeccable sealing.
3. Dual-sealing technology is employed to ensure that the flow is isolated from the spring, guaranteeing an exceptional leakage class.
4. Experience unparalleled stability and reliability with the enhanced sealing performance of our soft seat.
5. The innovative draining and sweeping design actively prevents jamming by thoroughly cleaning the valve.
6. Our product is meticulously crafted to comply with API 607 standards, offering robust fire-proof and anti-static capabilities.
SNT Machinery (Qingdao) Co., Ltd. stands at the forefront of control valve production, skillfully merging manufacturing prowess, innovative design, comprehensive sales, and exceptional service under one reputable brand. Strategically nestled in the vibrant city of Qingdao, Shandong province, our sprawling 42,000m² facility is a testament to modern engineering, complete with state-of-the-art workshops and cutting-edge production equipment. We are a proud high-tech enterprise, boasting independent intellectual property rights and enriched by global management and production expertise. Our dynamic team, over 150 strong, includes a remarkable 15% in R&D specialists and 30% with graduate or higher degrees. Driven by a commitment to excellence and groundbreaking research and development, we produce an array of top-tier valves for the petrochemical, oil, and coal chemical industries, achieving a commendable sales value approaching 100 billion in 2017.
SNT has achieved prestigious certifications, including the TS special equipment manufacturing certificate and ISO 9001. We hold the esteemed net qualification certificate from industry giants such as SINOPEC, CNOOC, PETROCHINA, and SINOCHEM. Our innovative spirit is further evidenced by numerous National Patents in various technologies. We excel in designing and manufacturing a comprehensive range of valves adhering to ANSI, API, DIN, BS, and JIS standards. By blending the best features from renowned global valves with our independent research, we have mastered the production of diverse valve types such as GLOBE, High Pressure Boiler Blow-down Valves, High-performance Butterfly Valves, Angle-regulating Valves, and Eccentric Rotary Valves.
Our extensive valve offerings also include T Three-eccentric Center Butterfly Valves, V Ball Valves, High Wear-resistant Ball Valves, High Pressure Steam Valves, Micro-flow Control Valves, Self-operated Control Valves, and Cryogenic Valves. We provide various driving forms including manual, power-driven, pneumatic, and hydraulic. Our main parts utilize robust materials such as A216WCB, A217 WC6/WC9, and A351 CF8/CF8M/CF3/CF3M. Specifications range from 1/2" to 120", with working pressures from ANSI 150# to 2500# and temperatures spanning -196ºC to 1100ºC.
Empowered by advanced production technology and a rigorous quality assurance system, SNT Valves are trusted across diverse industries including petrochemical, oil, steel & iron, paper manufacturing, and power stations. Our prestigious client roster features SINOPEC QILU branch, SINOPEC Qingdao branch, CNOOC Huizhou Refinery, PETROCHINA Guangxi branch, PETROCHINA Ningxia branch, among others, cementing our reputation as a preferred partner for excellence and reliability.
At SNT, we prioritize our customer's success, dedicating ourselves to crafting exceptional quality and building a respected brand. Our comprehensive quality assurance and responsive after-sales systems ensure that SNT valves foster enduring partnerships, paving the way for shared prosperity and growth with all our valued customers.
