Basic Info.
Driving Mode
Manual
Nominal Pressure
Pn10-Pn64
Channel
Straight Through Type
Structure
Floating Ball Valve
Type
Floating Ball Valve
Function
Shut-off
Temperature
-20~232
Application
Water,Oil,Air
Size Range
DN15~DN100
Body Material
Wcb/CF8/CF8m
Ball Material
CF8/CF8m
Seat Material
PTFE/Rptfe/Ppl
Transport Package
Carton Box+Plywood Case
Specification
CE
Trademark
WENBAO
Origin
China
HS Code
8481804090
Production Capacity
10000PCS/Month
Packaging & Delivery
Package Size
42.00cm * 24.00cm * 24.00cm
Package Gross Weight
600.000kg
Product Description
WB-15 2PC Stainless Steel Female Threaded Ball Valve
Company Overview
Features:
THREAD STANDARD: NPT, BSPT, DIN259, DIN2999, ISO228 CLASS A
MAX PRESSURE:6.4MPA
TEMPERATURE RANGE: -20C~232C
SUITABLE MEDIUM: WATER, OIL, AIR AND SOME CORROSIVE LIQUIDS
BLOW-OUT PROOF STEM/FULL PORT
INVESTMENT CASTING BODY
1000PSI(PN64) W.O.G
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308
Main Parts and Materials
| 1 | Body | CF8M/CF8/WCB | 8 | Packing | PTFE |
| 2 | Gasket | PTFE | 9 | Gland | SS304/SS |
| 3 | Cap | CF8M/CF8/WCB | 10 | Stem Nut | SS304/SS |
| 4 | Seat | PTFE | 11 | Handle | SS304/SS |
| 5 | Ball | SS316/SS304/SS | 12 | Spring Washer | SS304/SS |
| 6 | Stem | SS316/SS304/SS | 13 | Plastic Cover | Plastic |
| 7 | Thrust Washer | PTFE | 14 | Stem Nut | SS304/SS |
| NPS | DN | D | L | W | H |
| 1/4" | 8 | 11.5 | 53.5 | 93 | 51 |
| 3/8" | 10 | 11.5 | 53.5 | 93 | 51 |
| 1/2" | 15 | 13.5 | 62 | 93 | 55.5 |
| 3/4" | 20 | 17.5 | 74 | 110 | 59 |
| 1" | 25 | 22.5 | 87 | 125 | 68.5 |
| 11/4" | 32 | 29 | 105 | 145 | 75 |
| 11/2" | 40 | 35 | 108 | 170 | 86 |
| 2" | 50 | 48 | 125 | 170 | 96 |
| 21/2" | 65 | 65 | 154 | 210 | 127.5 |
| 3" | 76 | 80 | 177.5 | 240 | 134 |
| 4" | 100 | 100 | 228 | 314 | 160 |
