Basic Info.
Connection Form
Flange
Driving Mode
Manual or Pneumatic or Electrical
Nominal Pressure
PN1.0-32.0MPa
Channel
Straight Through Type
Structure
Floating Ball Valve
Type
Floating Ball Valve
Function
on-off Ball Valves
Temperature
-30degree to 180 Degree
Standard
DIN Standard
Application
Industrial Usage, Water Industrial Usage, Household Usage
Certificates
ISO9001-2015, CE
Seat Material
PTFE/Rptfe
Way Type
2 Way
Torque
Low Torque
Casting
Wax Lost Investment Casting Technology
Passway
Full Bore
Transport Package
Plywood Cases
Specification
DN15(1/2") to DN200(8")
Trademark
WELFLOW
Origin
China
HS Code
8481804090
Production Capacity
50000piece/Month
Packaging & Delivery
Package Size
10.00cm * 10.00cm * 10.00cm
Package Gross Weight
5.000kg
Product Description
Stainless Steel Flange Ball Valve with ISO 5211 High Mounting Pad
1. Pressure: DN15-DN50: PN40, DN65-DN150 PN16
2. Full Bore
3. Operation: Manual or Pneumatic/Electrical Actuator
4. Investment Casting Body
5. Blow-Out Proof Stem
6. Material: CF8(SS304)/CF8M(SS316)
7. Design and Manufactured according to DIN 3357
8. Face to Face Length is according with DIN 3202
9. The connection flanges are according to DIN 1092
10. Inspection and Test under EN1226.
Main Parts of Material
| NO | Parts Name | Material |
| 1 | Body | CF8/CF8M |
| 2 | Bonnet | CF8/CF8M |
| 3 | Ball | SS304/SS316 |
| 4 | Seat | PTFE/RPTFE |
| 5 | Stem | SS304/SS316 |
| 6 | Stem Washer | PTFE |
| 7 | Stem Packing | PTFE |
| 8 | Gland Nut | SS304 |
| 9 | Spring Washer | SS304 |
| 10 | Gland | SS304 |
| 11 | Stopper | SS304 |
| 12 | Spring Snap Ring | SS304 |
| 13 | Handle | SS304/SS |
| 14 | Spring Snap Ring | SS304 |
| 15 | Nut | SS304(A2-70) |
| 16 | Nut | SS304(A2-70) |
| 17 | Bolts | SS304(A2-70) |
Dimension(mm)
| Size | D | D1 | D2 | D3 | n-d | T1 | T | L | K | H |
| 1/2" | 15 | 45 | 65 | 95 | 4-14 | 2 | 16 | 115 | 9 | 80 |
| 3/4" | 20 | 58 | 75 | 105 | 4-14 | 2 | 18 | 120 | 9 | 85 |
| 1" | 25 | 68 | 85 | 115 | 4-14 | 2 | 18 | 125 | 11 | 90 |
| 11/4" | 32 | 78 | 100 | 140 | 4-18 | 2 | 18 | 130 | 11 | 100 |
| 11/2" | 38 | 88 | 110 | 150 | 4-18 | 3 | 18 | 140 | 14 | 115 |
| 2" | 50 | 102 | 125 | 165 | 4-18 | 3 | 20 | 150 | 14 | 125 |
| 21/2" | 65 | 122 | 145 | 185 | 4-18 | 3 | 18 | 170 | 17 | 145 |
| 3" | 80 | 138 | 160 | 200 | 8-18 | 3 | 20 | 180 | 17 | 152 |
| 4" | 100 | 158 | 180 | 220 | 8-18 | 3 | 20 | 190 | 17 | 175 |
| 5" | 125 | 181 | 210 | 250 | 8-18 | 3 | 22 | 325 | 27 | 242 |
| 6" | 150 | 205 | 240 | 285 | 8-22 | 3 | 22 | 350 | 27 | 270 |
| QUESTION? | ANSWER |
| 1. Are you a factory? | Yes, Welflow is a factory located in Wenzhou, Zhejiang, China. |
| 2. Do you have any requirements of MOQ? | No limited to MOQ but the difference in unit price. |
| 3. Payment Terms | Typically 30% T/T as deposit, 70% against copy of BL/ Or balance L/C at sight. |
| 4. Nearly Sea Port | Ningbo or Shanghai Port |
| 5. Terms: | FOB Ningbo/Shanghai, CIF, FCA, etc. |
| 6. Delivery Time: | Typically, it is 30-35 days after receiving the deposit payment. However, almost all of the items we have stock in 304. |
| 7. Could you accept color Marks or Color Boxes? | Yes, both are acceptable; we have experience with them. |
| 8. Could you accept marking our logo on the products? | Yes, on the handle or the bodies, both are okay. 1. Print on the Handle (NO MOQ requirements) 2. Laser Marking. (NO MOQ requirements) 3. Carvings(NO MOQ requirements) 4. Casting on the bodies (Has MOQ requirements) |
| 9. Do you have Material Certificates? | Yes, if required, Each item will be laser marked with Heat NO. and the material certificates. |
| 10. How do you deal with customer complaints, such as quality issues? | This is an issue we take very seriously. As long as it is confirmed to be a quality issue, we will take full responsibility. 1. exchange or refund is acceptable. It mainly depends on how you need to deal with it. |
Key Parts of Ball Valves
Body: The body of the valve, made from stainless steel, is the outer casing and provides the main structure. It contains the internal parts and has connections (ports) for the pipeline.
Ball: The ball is the central component that controls the flow of fluid. It's a sphere with a hole through the middle, which aligns with the pipeline when the valve is open and is perpendicular to it when the valve is closed.
Stem: The stem is the part that connects the handle to the ball. When the handle is turned, the stem rotates the ball.
Seat: The seats are rings of softer material (often PTFE or another plastic) that form a seal between the ball and the body when the valve is closed. There are typically two seats, one on either side of the ball.
Seals: Seals or packing material are used to prevent leakage along the stem. They ensure that when the valve is closed, no fluid can escape.
Bonnet: The bonnet is a part of the valve body that holds the stem. It's often bolted onto the body and provides a seal to prevent leaks.
